Advantech EKI-2541S-AE Ethernet to Single Mode Fiber
$506.99 NZD
Approx $287.63 USD
Normally: $509.99
Description:
Advantech EKI-2541S-AE Ethernet to Single Mode Fiber
EKI-2541S is designed to convert Ethernet networks to fibre networks by transparently converting Ethernet signals to optic signals. The advantages of fibre optics are wide bandwidth, EMI immunity and long-distance transmissions. Therefore, EKI-2541S is an ideal solution for “fibre to building” applications at central offices or local sites.
Specifications
| I/O | Transmission Distance | Ethernet: Up to 100m Multi-mode Fibre: Up to 2 km |
| Transmission Speed | Up to 100 Mbps | |
| Power Supply | Power Input | 12 ~ 48 VDC, redundant dual inputs |
| Power Connector | 6-pin removable screw terminal | |
| Operating System | Temperature (Operating) | -10 ~ 60°C |
| General | Power Consumption | 2.7W max. @ 48VDC |
| Power Input | 12 ~ 48 VDC, redundant dual inputs | |
| Ethernet Connectors | 1 x RJ-45 and 1 x SC type fiber connector | |
| Mounting | DIN-rail, Wall | |
| Dimensions (mm) | 37 (w) x 95 (d) x 140 (h) | |
| Interface | Ports Number | 2 |
Advantech EKI-2541S-AE Ethernet to Single-Mode Fiber Media Converter
The Advantech EKI-2541S-AE is a robust Ethernet to single-mode fiber media converter designed to seamlessly extend Ethernet networks over long distances using fiber optic cables. This device is ideal for industrial applications requiring reliable data transmission across challenging environments.
Key Features
-
Ethernet to Fiber Conversion: Converts 10/100 Mbps Ethernet signals to 100 Mbps single-mode fiber optic signals.
-
Long-Distance Transmission: Supports transmission distances up to 30 km over single-mode fiber, making it suitable for
wide-area network (WAN) applications.
-
Link Fault Pass-Through (LFP): Features an internal jumper for enabling LFP, which ensures that a link failure on one side
of the converter is propagated to the other side, facilitating quick fault detection.
-
Auto-Negotiation and MDI/MDI-X Crossover: Automatically adjusts to the network speed and duplex mode, and supports
automatic crossover detection, eliminating the need for crossover cables.
-
Redundant Power Inputs: Accepts a wide input voltage range of 12 to 48 VDC, providing flexibility in power supply options.
- DIN-Rail and Panel Mounting: Offers versatile mounting options to suit various installation environments.
-
Operating Temperature Range: Designed to operate in temperatures ranging from -10°C to +60°C, ensuring reliability in
diverse conditions.
Benefits
-
Enhanced Network Reach: Extends Ethernet networks over long distances without signal degradation, ideal for connecting
remote devices or facilities.
-
Improved Network Reliability: The LFP feature aids in quick fault detection and isolation, minimizing downtime.
-
Flexible Installation: Multiple mounting options and wide power input range provide flexibility in various industrial
setups.
-
Cost-Effective Solution: Utilizes existing Ethernet infrastructure while leveraging the benefits of fiber optic
transmission.
Why Choose the EKI-2541S-AE
The Advantech EKI-2541S-AE is a reliable and cost-effective solution for extending Ethernet networks using single-mode fiber. Its robust features, such as long-distance transmission, LFP, and flexible installation options, make it suitable for a wide range of industrial applications.
